2MP Tiandy TC-C320N IP Fixed Turret Camera with 30 m IR and Built-in Microphone
- Manufacturer:
- Model:TC-C320N-1CNB-28
- SKU:0023477
- 2000
- Weight:0.2 kg without packaging
- MP:2
Tiandy TC-C320N 1CNB-28 – 2MP IP Fixed Turret Camera for Everyday CCTV Tasks
The Tiandy TC-C320N 1CNB-28 is a compact 2MP IP Fixed Turret camera designed to deliver sharp Full HD (1920 × 1080) video at 30 fps in a discreet form factor. Its 2.8 mm lens with a wide horizontal field of view makes it ideal for monitoring entrances, small yards, reception areas, offices and retail spaces with a single camera.
Full HD image quality and reliable low-light performance
With a minimum illumination of 0.02 Lux in color and 0 Lux with IR on, the camera maintains usable images even when lighting drops. Smart IR illumination (850 nm) reaches up to 30 m, while the ICR cut filter ensures true day/night switching so scenes remain visible 24/7.
Image enhancement features such as DWDR, 3D DNR, BLC, HLC and Defog help to balance harsh backlight, reduce noise and improve visibility in foggy or high-contrast environments. Important details like faces and license plates stay readable in challenging scenes.
Weatherproof housing for outdoor installation
Thanks to its IP67-rated housing, the TC-C320N is ready for outdoor use in rain, dust and extreme temperatures. The operating range from −30 °C to +60 °C and humidity up to 95% RH allows the camera to work reliably all year round in different climate conditions.
Built-in surge protection up to 4 kV and ESD protection up to 6 kV reduce the risk of damage caused by lightning or electrical interference, making the camera a safe choice for exposed locations.
PoE, audio support and flexible integration
PoE support (IEEE 802.3af) with a maximum power consumption of only 2 W simplifies installation by using a single cable for both power and data transmission. The built-in microphone (G.711 A/U, 8 kHz) records audio alongside video, which is essential when investigating incidents or monitoring service quality.
The TC-C320N supports ONVIF Profile S/T, SDK and CGI, and is compatible with Milestone, Easy7 VMS and popular web browsers (IE10+, Edge, Chrome, Firefox, Safari). This ensures smooth integration into existing CCTV systems and easy configuration through a familiar web interface.
Order the Tiandy TC-C320N 1CNB-28 IP Fixed Turret Camera from GrandMall.Ge and equip your site with a reliable, energy-efficient and feature-rich CCTV solution.
SPECIFICATIONS:
- Color Maker - No
- Model - TC-C320N 1CNB-28
- Image Sensor - 1/3" Progressive Scan CMOS
- Resolution - 2MP
- Frame Rate - 30 fps @ 1080p
- WDR (Wide Dynamic Range) - DWDR
- Camera Color - White
- Focal Length - 2.8 mm Fixed
- Aperture Range - F2.0 (Fixed)
- Lens Type - Fixed Lens (M12 Mount)
- Field of View (FoV) - 93° (H), 53° (V), 104.8° (D)
- IR LEDs - 1 × 850 nm LED
- Night Distance - Up to 30 m
- Video Compression - S+265 / H.265 / H.264 B/M/H
- Smart Features - Smart IR, DWDR, 3D DNR, Motion Detection, Defog
- Audio Support - Built-in Microphone (G.711 A/U, 8 kHz)
- ONVIF Compliance - Profile S / T
- MicroSD Support - No
- Network Interface - 1 × RJ-45 (10/100 Base-T)
- Mounting Type - Ceiling / Wall Mount
- Power Supply - PoE (IEEE 802.3af), Max 2 W
- Operating Temperature - −30 °C ~ +60 °C, ≤95% RH
- Installation Temperature - −30 °C ~ +60 °C
- Product Dimension - 94 × 94 × 78 mm
- Product Weight (kg) - 0.17 kg
- Built-in Speaker - No
- Package Dimension - 105 × 105 × 85 mm
- Wi-Fi / 4G - No
- Package Weight (kg) - 0.25 kg
- Type - Indoor
- Access Channel - 1 Channel
