4MP Tiandy TC-C34XN Color Maker Turret Camera with 2.8 mm Lens and Built-in Mic
- Manufacturer:
- Model:TC-C34XN-2ENA-28
- SKU:0023438
- 2000
- Weight:0.3 kg without packaging
- MP:4
Tiandy TC-C34XN – 4MP Color Maker turret for vivid images around the clock
The Tiandy TC-C34XN 2ENA-28 is a 4MP Spark Series Color Maker turret camera designed to keep scenes clear and colorful even in low light. A highly sensitive 1/3" CMOS sensor, F1.6 2.8 mm fixed lens and dual IR/white LEDs work together to reveal people, vehicles and key details that standard IR-only cameras may miss.
4MP resolution and 2.8 mm wide-angle coverage
Delivering up to 4MP (2560×1440@30fps) video, the TC-C34XN provides enough detail to recognise faces, license plates and small objects. The 2.8 mm fixed lens offers a 91.5° horizontal, 51.2° vertical and 103.6° diagonal field of view, making it ideal for monitoring doors, checkout areas, offices and compact outdoor spaces with a single camera.
Efficient S+265/H.265/H.264 compression helps reduce storage and bandwidth usage while maintaining image quality. Image enhancement features including DWDR, 3D DNR, BLC, HLC and Defog improve visibility in challenging lighting conditions such as strong backlight, headlights or light fog.
Dual Light illumination, smart alarms and PoE installation
Two IR LEDs provide up to 30 m night vision, while two white LEDs add up to 15 m of warm visible light when color evidence is needed. Smart IR automatically adjusts brightness to avoid overexposure when subjects are close to the camera.
A built-in microphone records audio along with video, and smart alarms with human and vehicle detection help reduce false triggers from irrelevant motion. The metal and plastic IP66 housing, compact 117×117×96 mm body and PoE (IEEE 802.3af, max 4 W) support make the TC-C34XN easy to install on walls and ceilings indoors or outdoors.
SPECIFICATIONS:
- Image Sensor - 1/3" CMOS
- Min. Illumination - Color: 0.001Lux @ (F1.6, AGC ON); B/W: 0Lux with IR
- Shutter Time - 1s ~ 1/100000s
- Day & Night - IR-cut filter with auto switch (ICR)
- Smart IR - Yes
- WDR - DWDR
- S/N Ratio - >52 dB
- Angle Adjustment - 0~340°(Pan); 0~75°(Tilt); 0~360°(Rotate)
- Lens Type - Fixed focal lens
- Focal Length - 2.8 mm
- Lens Mount - M12
- Aperture Range - F1.6 (Fixed)
- Field of View - 91.5°(H); 51.2°(V); 103.6°(D)
- DORI Distance - Detect 56 m; Observe 22.2 m; Recognize 11.2 m; Identify 5.6 m
- IR LEDs - 2 pcs
- IR Distance - Up to 30 m
- IR Wavelength - 850 nm
- White LEDs - 2 pcs
- Whitelight Distance - Up to 15 m
- Video Compression - S+265 / H.265 / H.264B / H.264M / H.264H
- Video Bit Rate - 32 Kbps ~ 6 Mbps
- Audio Compression - G.711A / G.711U
- Audio Sampling Rate - 8 kHz
- Max. Resolution - 4MP, 2560×1440 @ 30 fps
- Main Stream - 2560×1440 / 2304×1296 / 1920×1080 / 1280×720 @ 25/30 fps
- Sub Stream - 704×576 / 704×288 / 640×360 / 352×288 (PAL); 704×480 / 704×240 / 640×360 / 352×240 (NTSC)
- BLC / HLC / AGC / 3D DNR - Yes
- Defog - Yes
- Privacy Mask - 4 black static areas
- Smart Alarm - Human and vehicle detection
- Network Protocols - RTSP, HTTP, TCP, UDP, ICMP, DHCP, DNS, NTP, IPv4, SSH, Unicast
- System Compatibility - P2P, ONVIF Profile S/T, SDK, CGI, Milestone
- Remote Connection - ≤ 2 clients
- Client Software - Easy7 VMS; EasyLive Plus (mobile)
- Communication Interface - 1 × RJ-45 (10/100 Base-T)
- Built-in Mic - 1 × Mic
- Power Supply - PoE: IEEE 802.3af, Max. 4 W
- Protection - Surge 4000 V; ESD 6000 V; IP66
- Operating Temperature - -30℃ ~ 60℃; ≤95% RH
- Storage Temperature - -30℃ ~ 60℃; 10% ~ 95% RH (non-condensing)
- Housing Material - Metal + Plastic
- Product Dimensions - 117(L) × 117(W) × 96(H) mm
- Package Dimensions - 140(L) × 140(W) × 120(H) mm
- Gross Weight - 0.38 kg
- Model - TC-C34XN 2ENA-28
